电流互感器MBS



最小起订货量

  • 无限制

您可能还关注相似产品
  • 主营产品|阀门
  • 公司荣誉|
供应产品分类
  • 暂无分类
本页信息为汉达森武志鹏原厂生产的产品“电流互感器MBS”产品信息,如您想了解更多关于“电流互感器MBS”价格、型号、厂家的相关信息,请致电我们,或QQ在线交谈。
品牌MBS 有效期至长期有效 最后更新2021-05-25 16:21
浏览次数10

电流互感器MBS

武志鹏
QQ:2850590584  点击这里给我发消息
手机:17718588643
电话:010-64714988-214
传真:010-64714988-668
邮件:tk3@handelsen.cn
武志鹏邮箱:tk3@handelsen.cn电话:010-64714988-214 武志鹏微信二维码
电流互感器MBS

  主要名称 电流:100 ... 600 A

  一次电线直径:最大28 mm

  一次剥皮1:30 x 10 mm

  一次剥皮2:2x 20 x 10mm
详情咨询177*1858*8643

  宽度:61 mm

  高度:75.5 mm

  深度:58 mm

  插入式电流互感器,其次级绕组可切换,初级电流范围为200-100 A至600-300 A,次级电流1或5 A,额定功率2.5至15 VA,精度等级为1。

  可以使用供货范围内的安装脚或标准DIN 35mm导轨的专用夹子来固定变压器。

  辅助触点可以用密封盖固定。

  一般性质

  没关系 连续热电流I cth:1.0 x I N

  没关系 短期热电流I th:60 x I N,1秒

  过流编号:FS5

  没关系 动态电流I dynes:2.5 x I th

  最高 工作电压U m:0.72 kV

  绝缘测试电压:3 kV,U eff,50 Hz,1分钟。

  标称频率:50赫兹

  绝缘等级:E

  防护等级:IP 20

  工作温度范围:-5°C至+ 40°C

  储存温度范围:-25°C至+ 70°C

  MBS型号示例:

  MBS ASR 14.3

  MBS ASR 20.3详情咨询177*1858*8643

  MBS ASR 21.3

  MBS ASR 21.5

  MBS ASR 22.3

  MBS ASR 22.3 2U

  MBS ASR 201.3

  MBS ASR 42.45

  MBS AS 176.3

  MBS ASK 176.3

  MBS ASK 205.3

  MBS ASK 21.3

  MBS ASK 31.3

  MBS ASK 31.3 2u

  MBS ASK 31.5

  MBS ASK 31.5 2u

  MBS ASK 31.6

  MBS ASK 318.3

  MBS ASK 31.4

  MBS ASK 31.4 2u详情咨询177*1858*8643

  MBS ASK 31.4 3u

  MBS ASK 41.3

  MBS ASK 421.4

  MBS ASK 41.4

  MBS ASK 41.4 2u

  MBS ASK 41.4 3u

  MBS ASK 41.5

  MBS ASK 41.6

  MBS ASK 412.4

  MBS ASK 412.4 2u

  MBS ASK 412.4 3u

  MBS ASK 541.4

  MBS ASK 51.4

  MBS ASK 51.4 2u

  MBS ASK 51.4 3u

  MBS ASK 561.4

  MBS ASK 51.6

  MBS ASK 61.4详情咨询177*1858*8643

  MBS ASK 61.4 2u

  MBS ASK 61.4 3u

  MBS ASK 61.6

  MBS ASK 63.6

  MBS ASK 81.4

  MBS ASK 81.4 2u

  MBS ASK 81.4 3u

  MBS ASK 63.4

  MBS ASK 83.4

  MBS ASK 101.4

  MBS ASK 101.4 2u

  MBS ASK 103.3

  MBS ASK 105.6

  MBS ASK 105.6 N

  MBS ASK 123.3

  MBS ASK 103.41

  MBS ASK 127.4

  MBS ASK 127.6

  MBS ASK 128.4

  MBS ASK 129.10详情咨询177*1858*8643

  MBS ASK 130.5

  MBS ASK 130.3

  MBS ASK 31.6

  MBS ASK 41.6

  MBS ASK 51.6

  MBS ASK 61.6

  MBS WSK 31.5

  MBS WSK 70.6

  MBS ASR 201.3

  MBS ASR 22.3

  MBS ASK 21.3

  MBS ASK 31.3

  MBS ASK 31.4

  MBS ASK 31.5

  MBS ASK 41.4

  MBS ASK 541.4

  MBS ASK 51.4

  MBS ASK 61.4

  MBS ASK 81.4

  MBS ASK 105.6

  MBS ASK 105.10

  MBS ASK 123.3

  MBS ASK 130.3

  MBS ASK 130.5

  MBS SWMU41.51

  MBS SWMU41.52

  MBS SWMU42.51

  MBS SWMU42.52

  MBS ASR 14.3 50/1A 1.5VA Cl.3

  MBS ASR 14.3 50/1A 1VA cl.1

  MBS ASR 14.3 50/1A 1.5VA Cl.1

  MBS ASR 14.3 60/1A 1.5VA Cl.1

  MBS ASR 14.3 75/1A 1.5VA Cl.1

  MBS ASR 14.3 30/1A 1VA Cl.3

  MBS ASR 14.3 50/5A 1VA Cl.1

  MBS ASR 14.3 50/5A 1.5VA Cl.1

  MBS ASR 14.3 60/5A 1.5VA Cl.1

  MBS ASR 14.3 75/5A 1.5VA Cl.1

  MBS ASR 14.3 30/5A 1VA Cl.3

  MBS ASR 14.3 40/5A 1VA Cl.3

  MBS CTM 7 35/1A 0,2VA Kl.1

  MBS CTM 7 40/1A 0,3VA Kl.1

  MBS CTM 7 50/1A 0,4VA Kl.1

  MBS CTM 7 60/1A 0,4VA Kl.1

  MBS CTM 7 64/1A 0,5VA Kl.1

  MBS ASR 14.3

  MBS ASR 20.3

  MBS ASR 201.3详情咨询177*1858*8643

  MBS ASR 21.3

  MBS ASR 21.5

  MBS ASR 22.3

  MBS ASR 42.45

  MBS ASR 22.3 2U

  MBS ASG 210.3

  MBS ASG 106

  MBS ASG 123

  MBS AS 176.3

  MBS ASK 176.3

  MBS ASK 205.3

  MBS ASK 21.3

  MBS ASK 231.5

  MBS ASK 31.3

  MBS ASK 318.3

  MBS CTB 31.35

  MBS ASK 31.4

  MBS ASK 31.5

  MBS ASK 31.6

  MBS ASK 41.3

  MBS ASK 421.4

  MBS CTB 41.35

  MBS ASK 41.4

  MBS ASK 41.5

  MBS ASK 412.4

  MBS ASK 41.6

  MBS ASK 541.4

  MBS CTB 51.35

  MBS ASK 51.4

  MBS ASK 51.6

  MBS ASK 561.4

  MBS CTB 61.35

  MBS ASK 61.4

  MBS ASK 61.6

  MBS ASK 63.4

  MBS ASK 63.6

  MBS CTB 81.35

  MBS ASK 81.4

  MBS ASK 83.4

  MBS CTB 101.35

  MBS ASK 101.4

  MBS ASK 103.3

  MBS ASK 103.41

  MBS ASK 105.6

  MBS ASK 105.6N

  MBS ASK 123.3

  MBS ASK 127.4

  MBS ASK 127.6

  MBS ASK 128.4

  MBS ASK 129.10

  MBS ASK 130.3

  MBS ASK 130.5

  MBS ASK 165.5

  MBS ASK 205.5

  MBS ASK 31.3 2U

  MBS ASK 31.4 2U

  MBS ASK 31.4 3U

  MBS ASK 31.5 2U

  MBS ASK 41.4 2U

  MBS ASK 41.4 3U

  MBS ASK 412.4 2U

  MBS ASK 412.4 3U

  MBS ASK 51.4 2U

  MBS ASK 51.4 3U

  MBS ASK 61.4 2U

  MBS ASK 61.4 3U

  MBS ASK 81.4 2U

  MBS ASK 81.4 3U

  MBS ASK 101.4 2U

  MBS ASK 103.41 2U

  MBS WSK 30

  MBS WSK 40

  MBS WSK 40N

  MBS WSK 60

  MBS WSK 70.6

  MBS WSK 70.6 N

  MBS WSK 31.5

  MBS KBR 18

  MBS KBR 32

  MBS KBR 44

  MBS KBU 23

  MBS KBU 58

  MBS KBU 812

  MBS KSU 2

  MBS KSU 3

  MBS SUSK 3

  MBS SUSK 4

  MBS SUSK 5

  MBS SUSK 6

  MBS SUSK 7

  MBS SUSK 8

  MBS NH 6.1

  MBS NH 6.2

  MBS NH 6.3

  MBS NH 6.1 2U

  MBS NH 6.2 2U

  MBS NH 6.3 2U

  MBS SASR 22.3

  MBS SASK 21.3

  MBS SASK 31.5

  MBS SASK 31.6

  MBS SASK 421.4

  MBS SASK 41.4

  MBS SASK 41.6

  MBS SASK 41.10

  MBS SASK 541.4

  MBS SASK 51.4

  MBS SASK 51.6

  MBS SASK 61.4

  MBS SASK 61.10

  MBS SASK 63.6

  MBS SASK 105.6

  MBS ASRD 14

  MBS ASRD 210.3

  MBS ASRD 205.37

  MBS ASRD 310.37

  MBS ASK(D) 21.3

  MBS ASK(D) 31.5

  MBS ASKD 31.8 mit Bodenplatte

  MBS ASKD 31.8 ohne Bodenplatte und Nullleiter

  MBS ASK(D) 31.5 2U
